Converting Equipment

120” Web Black Clawson Rewinder; 72” Shaftless Rewind, Lowering Table; Speed: 3000 FPM; Shear Slitting; Rewind Diameter: 72”; Black Clawson Shaftless Floor Pick-Up Unwind, 72” Diameter, Year 1989.

Two (2) 60” NDC Scanners, Model 8200, Back-up software disk included. Radioactive source removed. New in 2019 with only sporadic usage since installed. Capable of thickness testing and coating basis weight measurement.

60” Width x 60” Diameter Davis Standard (ER-WE-PA) Turret Unwind; Dual Spindle Turret 3", 6" Core Diameter; Automatic Splicing Unit; With Web Guidance; Dancer System with Potentiometer Feedback Tension Control; Year: 1986/2004 / S/N: 8516-1037.

54” Automatic Splice Drum Surface Winder / Reel; Mfg. Davis Standard (ER-WE-PA). 54” Roll Width x 60” Diameter; 56.5” Drum Width; 36” Drum Diameter; 6” Air Shafts; Auto Shaft Pulling and Loader Accessory. Year: 1986/2004 S/N: 8516-1037.

130" Horizontal Track Reel, Manufactured by GL&V. Dimensions: 129.25" Drum Face, 84" max Roll Diameter. Year 2018 Upgrades: Include New Primary & Secondary Arms for added automation and control. Reel was rebuilt utilizing the existing reel drum, reel bases, and reel doctor. New Primary and Secondary Arms were added with new Pneumatic cylinders and controls and other drive components.

60” Dual Spindle Turret Unwinds; 60” Diameter; Quantity (3); Capacity: 40,000 lbs.; Includes 60” Ultrasonic Flying Splice. Mfg. by Toko; Year 2000. Formerly used for film converting.

60" High Performance Turret Unwind / Rewind Pair, 60" Diameter on Unwind / Rewind. Shaftless design. High speed flying splice. Drives and Controls included. Formerly used in film converting operation.

72” Roll Storage Carousel for 158 Rolls of varying widths and diameters built by Fab-Tech in 2001. Capacity: (158) Carriages with Avg. load of 500 lbs. per carrier. Total weight capacity is 79,000 lbs. with a Max 677 lbs. per carriage. Total (158) Rolls Maximum. Retrieval Time (avg.): 4 minutes 3 seconds. Roll Widths: 48” – 72”; Roll Diameters: 3.5” – 13.75”. Year 2001. Machine Dimensions: 32’-10” H x 26’-5” D x 13' W

36” Wide Six (6) Color Kidder CI Flexographic Press. Features Kidder 649 Updated Drives and Controls Doctor Blades on all decks. Also includes (6) spare Doctor Blade units for quick change over and (6) spare anilox rolls. Has 24” O.D. Turret Unwind and Rewind Overhead Gas Drying and Web Guides on Infeed and Outfeed.

American Baler Co. Model 350 NSB Top Fed Horizontal Baler 100 HP 44/3/60 Electrical

Quantity (2); Model VAZ 300 / 250 UNF Vecoplan Shredders; 5344-010 Machine Number; Rebuilt “As New” In 2022; Mfg. Year 2001; Rotor: 620mm Diameter; 2491mm Length; Speed: 142 RPM; Main Drive: Electric Motor with Fluid Coupling, Joint Shaft, Two Step Spur; Spur Gear Ratio: 12.5 to 1; Nominal HP: 192 Kw; Nominal Amps: 332A; Motor RPM: 1782; Electricals: 460V / 3 Ph / 60 Hz.

51” CMF 6 Color CI Press with Gas Drying. 24” Diameter Turret Unwind and Rewind Pro-Scan Quality Control Camera View Doctor Bladed Print Stations. Includes (60) Plate Cylinders and (7) Extra Anilox rollers. Currently running for a short time only.

106'' Web Width One (1) Color Wolverine Print Deck Built on a one-color cast-iron frame. Full Print Width: 105”. Repeat Length Range: 18'' – 40”. Impression Cylinder: 7.958” Diameter. Anilox Roll: 7.810” Diameter. Includes:- Doctor Bladed Anilox Roll- 1/4 CP gearing.- Three (3) 6'' stainless steel slot type air distribution tubes.

58” Standex Rotary Metal Embosser. Standex Engraving Mark 250 SP Rotary Hydraulic Metal Embosser. Designed to Run as Sheet Fed or Continuous operation. 54" Maximum Material Width. Designed for Metal Embossing, Aluminum or Stainless Steel. The Embosser is a Stand-Alone Machine. Manufactured 2015. Like new condition.

90” Web Kusters Embossing Calender 3-Roll Stack. Includes (2) two Kuster S-Roll with engraved embossing patterns one (1) middle position heated tri-pass roll. Rolls have a 102” Face Width and 20” Diameter. Includes hydraulic system and oil heating system and drive motors. Previously used for processing Non-Wovens.

5.8 Meter (228”) Bombi Three-Roll Nonwoven Calender; Type CAL/3C/5.8; 3-Roll; Working width 5800mm; Roll Width 6100mm (240”); Roll Diameter: 800mm (31.5”); Pressure approx. 25 Tons (240 PLI); Oil Heated; Year: 2007.

62” Width x 50” Diameter Black Clawson Turret Unwind with Auto Splicing. The unwind is from a rotogravure coating line now out of operation. Includes Transfer Station for auto splicing.

62” Width x 50” Diameter Black Clawson Turret Rewinder with Splicing. The rewinder is from a rotogravure coating line now out of operation. Includes Transfer Station for auto splicing.

144" Drum Width Paper machine winder, Black Clawson, 2-Drum slitter rewinder. Roll Diameter: 60"; Operating speed 2500-3000 FPM. Originally manufactured late 1960’s. Previous paper grade was light weight specialty paper.

Perini Core Winding Line 2 PLY. MFG 1996. Consisting of (2) Mod# 4203 unwind stands with dancer unit. Cardboard Reel unwind capable of 60" (1524mm) OD rolls and reel hoisting lift. Valco cold glue system. Unit has Core loader and core hopper. Video Jet Printer.
